Accessing Video from a Samsung SDR-3001N DVR

Last week I had a rough day. Well, not really rough… mostly it just made me embarrassed to be a technologist. My role in this debacle was kind of fun.

I spent most of a day trying to get a video file off of a Samsung SDR-3100N DVR that’s hooked up to the security cameras at my condo. I managed to get the files off, and convert them into a usable format, but it was pretty painful. Here’s a writeup, just in case someone else has to deal with this mess.

Background

We’ve been using this Samsung SDR-3100N for years, but we haven’t ever had to access the video. Security cameras are a bit like disaster recovery. You don’t know if they work until you really need the video. Last week we needed the video.

Last week a couple of police officers knocked on our door. We learned that some jerkfaces broke into a bunch of bars near my house… on Christmas. It seems that they drove their vehicles past my condo’s security cameras, and the police wanted the video footage to aid in their investigation.

While they patiently watched, I attempted to access the video. The mobile app didn’t work. I grabbed a laptop. The Wifi access point didn’t work. I plugged into the switch with an Ethernet cable. The DHCP on the security camera’s network didn’t work. Plugging the laptop directly into the DVR and sniffed ARP traffic. There wasn’t any. It seems that entropy had set in and broken every piece of technology attached to the security cameras.

Not wanting to waste their time, I promised to send them the video files. We exchanged contact info, and my pretend forensics work began.

Using the DVR as intended

If you just want to get video off of your DVR, skip over this section. It was unsuccessful.

Attempt 1: The web interface

I unhooked the security DVR, plugged it into my working home network, and fired it up. It seemed OK. It booted with a harsh beep noise, and a green LED. I saw it get an IP address. It’s alive!

The mobile app connected and was able to see live video, but it could not find any previously recorded video.

The mobile app was pretty light in administrative features, so I could not investigate the root cause. But, it’s supposed to have a web interface. So, I typed its IP address into Chrome and gave it a poke. It demanded that I access it with IE or Safari (although the JavaScript it loaded seems to indicate that Firefox is also acceptable). I fired up Safari, and gave it another poke. A login page! And beyond that… a message that I need to install Microsoft Silverlight :(

But here’s the kicker, it wanted me to install an unsigned Silverlight binary delivered from the DVR itself.

I downloaded a signed Silverlight binary from Microsoft, but it still complained that I needed to install its fishy Silverlight binary. It turns out that Safari’s security settings disables Silverlight on all website by default. I enabled it for all websites by toggling ‘unsafe mode’, and gave it one more try.

This got me one step further. I was greeted by two loading spinners that displayed no content. This is where I stopped. I didn’t feel like reverse engineering their ancient web app. There has to be a more sensible way.

Attempt 2: Updating the firmware

Maybe the software is just too old for modern browsers. If that’s the case there has to be a firmware update, right? Nope. The Samsung support webpage does not even have a listing for this DVR, which they sold until 2013.

Poking around a bunch of forums didn’t turn up much either. As far as I can tell, they’ve never released any firmware updates for this product… ever. I couldn’t even find a mention of firmware updates in the paper instruction manual.

Attempt 3: Plug it into a monitor

The security DVR had spent its whole life in headless mode: it was never connected to a monitor. But it certainly has that capability. You can plug it into either a BNC composite display, or a VGA monitor to watch live feeds directly. This is perfect if you want to role-play one of those action movie scenes where a ninja knocks out security cameras one at a time while the security guard’s panic increases from dropped doughnut to spilled coffee. However, this option is not perfect for me. I have 0 display devices capable either VGA or BNC composite. But I do have a TV that can display RCA composite video. Rather than walk a block to buy an adapter, I hacked this up… and it worked!

When I carefully placed this delicate disaster near my TV, I could watch it boot up!

It was a dead end. After many minutes of booting up, it only displayed SAMSUNG across my TV in big letters. Fiddling with the remote control or a USB mouse didn’t do anything.

This is when I flipped form lawful neutral to chaotic neutral. It’s also when I reached for a screwdriver.

Getting at the video files some other way

I opened up the DVR and found a SATA hard disk inside. I plugged it into a USB write-blocker and connected it to my mac. diskutil reported it to be a Linux disk, but neither ext-fuse nor Paragon’s EXTfs driver could mount it. I’m not sure what’s up with that.

But I had another option: Kali linux on the laptop I took to DEFCON. And sure enough, it was able to read the disk. Oddly it had two partitions, both named NATALIE. The big NATALIE partition contained 500GB of video in ssf files all dated 2001. It seems that the real-time clock battery died at some point. The mobile app probably would have worked, if I had paged back to 2001. It’d be nice is the mobile app had told me that.

Anyway, I copied the files to another disk drive, this one formatted with exFAT so I could access them from my macOS laptop. Neither preview nor VLC were able to open the ssf files, but ffprobe displayed a lot of warnings and details about a single h264 video steam.

$  ffprobe 010404035310_000.ssf
... lots of warnings ...
Input #0, h264, from '010404035310_000.ssf':
  Duration: N/A, bitrate: N/A
    Stream #0:0: Video: h264 (Constrained Baseline), yuv420p(progressive), 352x240, 25 fps, 25 tbr, 1200k tbn, 50 tbc

And ffmpeg was able to copy the stream to a more typical container.

$  ffmpeg -i ./010404035310_000.ssf -c copy 010404035310_000.mp4
... ~5000 lines of warnings ..
frame=513808 fps=48048 q=-1.0 Lsize= 1915044kB time=05:42:32.42 bitrate= 763.3kbits/s speed=1.92e+03x
video:1912815kB audio:0kB subtitle:0kB other streams:0kB global headers:0kB muxing overhead: 0.116570%

Note the exponential notation on the speed. Aren’t modern disks wonderful?

And this resulting mp4 file works in VLC, but looks terribly corrupted. It seems that all of the video cameras have been smashed into a single h264 video stream, and players get really confused. It looks like compressed P-frames refer to the wrong complete I-frames. After trying a bunch of different video players and editors, Adobe Premier seems to read the video with the least corruption.

Blinky footage

I tinkered around with ffmpeg but was unable to coerce it into reshuffling the frames. It didn’t like the idea of extracting a raw P-frame or attaching it to a different I-frame. But, you can remove the corruption by filtering out the confused P-frame references. You can use ffmpeg to pull out the I-frames (aka keyframes).

$ ffmpeg -i 010404035310_000.mp4 -vf select="eq(pict_type\,PICT_TYPE_I)" -vsync 0 iframe%03d.jpg
... cpb: bitrate max/min/avg: 0/0/200000 buffer size: 0 vbv_delay: -1
frame=    4 fps=0.0 q=5.6 Lsize=N/A time=00:00:06.03 bitrate=N/A speed=16.8x
video:468kB audio:0kB subtitle:0kB other streams:0kB global headers:0kB muxing overhead: unknown

This yields a bunch of sharp jpg files. This is also where I stopped my analysis.

Conclusion

I was able to access the video, and review footage until I found what I was looking for. I also changed the real-time clock battery in the DVR, so the mobile app should work better now.

But, that was a pretty rough experience. I can’t imagine what a typical non-technical user would do, or even a technical user who didn’t have a day to kill tinkering with a broken-by-design security DVR. Samsung: shame on you.

I’d love to replace this DVR with something better, but all of the options I can find seem to suffer from the same terrible software and lack of updates. Now I understand why magic cloud cameras, like the Nest camera, are so appealing.


Moving out of Amazon Drive

tl;dr:

I’m moving my data out of Amazon Drive (formerly known as Amazon Cloud Drive). I have 4TB across 1,000,000 files. I’ve struggled to download my data, but I found some tricks to make it easier. Here they are in a handy listicle.

More detail

Every couple of years, someone announces an unlimited capacity cloud storage product targeted at consumers. Then, inevitably, a few jerks with multiple terabytes of data swoop in and ruin the deal for everyone.

I’m one of those jerks. I’ve migrated 4TB of data from one consumer cloud storage provider to another over the course of several years.

With their prices increasing significantly, it gave me a challenge: download all of my data using only the official sync client. This blog entry describes the lessons I learned from that process.

When you install Amazon Drive, you can select a folder to use for synchronization. On macOS the default is ~/Amazon Drive, and the setup configurator prevents you from pointing it to a removable disk. This is a bummer because modern computers have smaller, faster boot disks. None of my computers have a boot disk bigger than 1TB.

Changing the configuration file in ~/Library/Application Support/Amazon Cloud Drive seems to make the sync client angry, but there is another way: symbolic links.

# Dangeously stop the sync client with this shell-fu, or just quit from the menu
$ ps -ef | grep 'Amazon Drive'  | awk '{print $2}' | xargs -n1 kill
# Delete the old target
$ rm -rf '~/Amazon Drive'
# Swap in your removable storage
$ ln -s /Volumes/4tb/ '~/Amazon Drive'

The client is happy to sync down to a removable disk behind a symlink, but I have no idea what will happen if the disk is removed while the client is working (I found out… it purges all client metadata, and you have to start over). So, don’t do that.

Tip 2: Use a SSD boot disk

tl;dr:

Your sync host computer must have an SSD boot disk. The sync client has very poor performance when managing metadata on spinning disks.

Details

My primary computer is a laptop. I often carry it with me. This means it’s disconnected from the Internet, and not a great sync host.

I had this brilliant idea of dusting off an old mac mini from 2011, putting the Amazon Drive sync client on it, and letting it churn away for a few days to recover all of my data.

This did not work. First, Amazon Drive spent two days Preparing. After that, file synchronization proceeded at about 10 files per minute, regardless of their size. There were a few spikes of CPU and network usage, but nothing that explained the glacial pace. At this pace, it would not finish until early October.

I did what any engineer would do, and whipped out dtrace. A little probing found the problem. The sync client was doing a staggering number of tiny, scattered I/O operations. This probably has something to do with their heavy use of SQLite. Check this out:

~/Library/Application Support/Amazon Cloud Drive$ ls -l
-rw-r--r--   1 mim  eng  758280192 Jul 31 00:58 amzn1.account.MSSM74Z-cloud.db
-rw-r--r--   1 mim  eng      32768 Jul 31 12:00 amzn1.account.MSSM74Z-cloud.db-shm
-rw-r--r--   1 mim  eng  212966952 Jul 31 14:55 amzn1.account.MSSM74Z-cloud.db-wal
-rw-r--r--   1 mim  eng       4096 May 28 14:24 amzn1.account.MSSM74Z-download.db
-rw-r--r--   1 mim  eng      32768 Jul 31 12:00 amzn1.account.MSSM74Z-download.db-shm
-rw-r--r--   1 mim  eng    2171272 Jul 31 14:00 amzn1.account.MSSM74Z-download.db-wal
-rw-r--r--   1 mim  eng        129 May 28 14:25 amzn1.account.MSSM74Z-settings.json
-rw-r--r--   1 mim  eng   81358848 Jul 31 14:56 amzn1.account.MSSM74Z-sync.db
-rw-r--r--   1 mim  eng      65536 Jul 31 14:31 amzn1.account.MSSM74Z-sync.db-shm
-rw-r--r--   1 mim  eng   44982192 Jul 31 14:56 amzn1.account.MSSM74Z-sync.db-wal
-rw-r--r--   1 mim  eng       4096 May 28 14:24 amzn1.account.MSSM74Z-uploads.db
-rw-r--r--   1 mim  eng      32768 Jul 31 12:00 amzn1.account.MSSM74Z-uploads.db-shm
-rw-r--r--   1 mim  eng    2171272 Jul 31 14:00 amzn1.account.MSSM74Z-uploads.db-wal
-rw-r--r--   1 mim  eng        352 Jul 31 13:01 app-settings.json
-rw-r--r--   1 mim  eng        368 May 28 14:24 refresh-token
-rw-r--r--   1 mim  eng         32 May 28 14:23 serial-number
~/Library/Application Support/Amazon Cloud Drive$ sqlite3 amzn1.account.MSSM74Z-cloud.db 'select count(*) from nodes;'
1077668
~/Library/Application Support/Amazon Cloud Drive$

Yeah, that’s over a gigabyte of SQLite databases! Some tables have more than a million records. Count queries take a few seconds, and toggling an option in the client sometimes can trigger millions of SQLite queries across multiple databases. This had the read head of my spinning disk thrashing back and fourth. Fortunately, random access penalties are much lower on SSDs.

Tip 3: Take smaller bites

The client is more stable when attempting to sync fewer files in one batch. Sync at most 100,000 files at a time, allow it to finish, and then sync another batch.

If you try to sync too many files at once, the client gets CPU and memory hungry, slows down, and becomes unstable. If the sync request is over 1,000,000 files, the client may start crashing on launch. Once this happens, you must delete the SQLite databases, and start over.

Tip 4: Don’t copy files into the sync path

Don’t copy files into sync client’s target path. This means no attempting to help it along by copying in previous partial download attempts. Let the client sync every file down itself.

Copying files into the sync path confused my sync client, and it delete a bunch of stuff from Amazon Drive. If you suspect this happened, don’t panic. You have a few days to restore files from the web interface. Sign in, navigate to trash, and restore deleted files from there.

Conclusion

At this pace, I’ll be able to download all of my data out before the new rates hit for me. Yay!

In retrospect I should have written my own sync client on the API, or tried to get the possibly-banned rclone client working. However, I did enjoy the adventure in exploring how the sync client works.

With this migration wrapping up, I’ve given up on consumer cloud storage products. They’re too painful to use for large volumes of data. It’s time to switch to an enterprise storage product so I can use real APIs to move data around, and benefit from SLAs and deprecation policies.

Update

I shared this post around, and got some great feedback on r/DataHoarder, the subreddit for people who laugh at my meager 4TB of accumulated data.

Here are their proposed solutions:

  • The Syncovery client supports Amazon Drive. The interface is a bit complicated, but it actually works! I was able to slurp my data down using the trial, and plan to purchase a real license next time I need to cart my data around.
  • The Amazon Cloud client runs on Windows Server. So, if the final home of my data is Google Cloud Storage, I could run it on a Windows virtual machine.

Thanks for the advice Redditors! :)


Windows XP at DEFCON: Preparation

I’m on my way to my first ever DEFCON. It’s a very popular hacker / cybersecurity conference in Las Vegas that some people compare to Burning Man for hackers. I’m super excited.

Over the years I’ve received advice about how to survive the event without getting pwnd. The advice ranges from don’t use the open wifi with your work laptop to don’t bring any electornics at all.

But, I’m a fool. So instead, I’m bringing the least secure computer possible to see how deep pwnage can go. Then, after the event, I’ll try to figure out what happened.

Laptop & OS selection

You’d think this would be as easy as finding a Lappy 486 at a thrift store and slapping Windows ME on it, but you’d be wrong. Laptops that old can’t connect to modern wifi, and might not even be able to mount malicious USB devices. I’d probably go the whole conference without getting hacked, and that’s unacceptable.

I need vulnerabilities that are still in the wild, and a computer that is capable of connecting to modern wifi networks. Specifically, I need a computer that meets these requirements:

  • Vulnerable to attacks that people still remember
  • Capable of connecting to modern wifi and USB drives
  • Swappable boot disk, in case it becomes unusable in the middle of a session
  • Cheap enough that I won’t feel bad if someone manages to kill it entirely

Laptop Fail: Ideapad U110

I discussed this with my helpful coworkers. One of them had recently found a laptop in a recycling heap: a Lenovo Ideapad U110. It seemed to meet most of my requirements, and had a bonus feminine red case.

I started adjusting it to fit my needs, but quickly encountered some issues. The boot disk was connected with a delicate, proprietary ZIF40 cable, and required partial disassembly to access. I attempted to repurpose some components widely available for iPod hacking to change it to a CompactFlash, but I only ended up learning way too much about the challenges of booting Windows XP from CompactFlash.

After hours of hacking away I coerced Windows XP to install, and boot off of a comically long chain of adapters: ZIF40 to CompactFlash to SD to MicroSD. Unsurprisingly, it was slow and flaky. It booted about 30% of the time.

I decided my time was better spent coming up with easter eggs, so I cleaned up the U110, and moved on.

Laptop Win: Thinkpad X220

A couple hours of research turned up the Thinkpad X220. It met all of my minimum requirements, and was a respectable laptop in its day. I snagged one in great shape for under $100 on ebay.

I picked up some 16GB SATA SSDs that fit great once I removed some of the drive casing. Installing Windows XP on this laptop went smoothly, and drivers were pretty easy to find from official sources.

The only challenge I encountered was around programmable chips on the main board. I know that the BIOS, WiFi module, and several other components could conceivably be reprogrammed, but I was unable to figure out how to dump them, or even get a checksum. All I could find was a mysterious CD-ROM bootable BIOS flasher. Theoretically, this should help me recover from a compromised BIOS, but reverse engineering it to get a checksum was one too many yaks to shave.

All the ThinkPad needed was some Windows XP era tech stickers, and it was ready to go!

Easter eggs

With the laptop usable, I had to make it worth exploring to my hacker friends. I registered 5 new email accounts, and hid them in various places about the laptop. Some are pretty easy to find, others are hidden behind riddles that I’m not sure anyone will solve.

Hopefully, someone will find some of them and drop me an email to say hi :)

The DEFCON plan

Here’s the full project kit. It includes:

  • An ethernet cable for plugging into suspicious ports
  • A big USB disk, for saving images of compromised boot disks
  • The IBM X220, dubbed Not a honeypot by my friends
  • An LTE wifi hotspot, for slightly less corrupt Internet access
  • A Windows XP install CD and USB CD-ROM, just in case all of my boot disks get trashed
  • 3 extra boot disks for easy swapping on the go
  • Kali Linux on a bootable USB stick, for imaging compromised boot disks
  • A drive duplicator, for restoring clean Windows XP installations
  • A USB SATA reader with write blocker, for capturing boot disk images

Once I make it to DEFCON, I plan to engage the conference community through a variety of channels:

  • If I can connect to a wifi SSID, I’ll connect and try to surf the web
  • If I see a USB thing, I’ll plug it in and see what happens
  • If there’s an ethernet port, I’ll connect to that too

If the laptop becomes unusable due to excessive pwnage, I’ll swap the boot drive and repeat. Whenever I get a break I’ll save an image of the compromised disk and restore it to a clean Windows XP installation.

Hopes and Fears

I hope that I’ll encounter a variety of interesting attacks that will be educational and enjoyable to investigate for weeks to come. I hope I make some new friends who each out to me on the planted email addresses. But, projects like this one rarely go as planned.

It’s possible that every time I boot up, my laptop immediately stops working, and every time it’s for the same boring reason. That’d be a bummer, but I can deal with that by actually patching some of the vulnerabilities or running a different operating system.

It’s also possible that nothing happens. If I make it a day without any visible intrusion, I’m going to step it up a notch. I’ll fire up a bunch of known insecure services like obsolete versions of IIS, MySql, and WordPress.

In any case, I’m going to find out soon. Wish me luck, and check back later for an update on the aftermath.
